Parameters:

  • Model:S-8353H30MC
  • Manufacturer:HUABAN
  • Date Code:05+NOPB 05+nopb
  • Standard Package:3000
  • Min Order:10
  • Mark/silk print/code/type:1WP
  • Package:SOT-153/SOT23-5

控制方式
MODE
PWM
输入电压VIN
Input Voltage
1.8~6V
输出电压VOUT
Output Voltage
3V
输出电流IOUT
Output Current
160mA/0.16A
震荡频率FOSC
Oscillation Frequency
1.113MHz
内置FET
Built-in FET
Description & ApplicationsPWM CONTROL or PWM / PFM SWITCHABLE BUILT-IN TRANSISTOR SWITCHING REGULATOR • Low voltage operation: 1.8 V to 6.0 V • Oscillation frequency: 286 kHz to 1.133 MHz (selectable by external resistor) • UVLO (under-voltage lockout) function: •Detection voltage can be selected from between 1.5 V and 2.3 V in 0.1 V steps. •Hysteresis width can be selected from between 0.1 V and 0.3 V in 0.1 V steps. • Timer latch short-circuit protection circuit: •Delay time can be set using an external capacitor. • Soft-start function: Soft-start time can be selected in three steps, 10 ms, 15 ms, and 20 ms. • Phase compensation external setting: •Adjustable by connecting resistor and capacitor in series to GND. • Shutdown function: S-8338 Series, shutdown current consumption: 1.0 μA max. • Lead-free, Sn 100%, halogen-free • Power supplies for LCDs and CCDs • Power supplies for portable equipment
描述与应用PWM控制或PWM / PFM切换 内置的晶体管开关稳压器 •低电压工作:1.8 V到6.0 V •振荡频率:286 kHz至1.133兆赫(由外部电阻选择) •UVLO(欠压锁定)功能: •检测电压可以从1.5 V和2.3 V之间,在0.1 V步骤。 •迟滞宽度可以选择从0.1 V和0.3 V,0.1 V步之间。 •定时器锁存短路保护电路: •延迟时间可以设置使用一个外部电容器。 •软启动功能:软启动时间可以选择三个步骤,10毫秒,15毫秒,20毫秒。 •外接设定相位补偿: •通过连接到GND串联电阻和电容可调。 •关机功能:S-8338系列,休眠时消耗电流1.0μA最大值。 •无铅,SN100%,无卤素的 •电源,LCD,CCD等 •用于便携式设备的电源供应器

×
