BAT15-04 series connection SBD Schottky Barrier Diodes 4V 110mA/0.11A 320mV/0.32V SOT-23/SC-59 marking S8 DBS mixer applications to 12 GHz

Model：BAT15-04
Mark / screen / code / typing：S8
Manufacturer：
Date Code：07+ROHS 05+
Package：SOT-23/SC-59
Standard Package：3000
Min Order：10

Hot selling goods

Product description

反向电压Vr Reverse Voltage	4V
平均整流电流Io AVerage Rectified Current	110mA/0.11A
最大正向压降VF Forward Voltage(Vf)	320mV/0.32V
最大耗散功率Pd Power dissipation	100MW/0.1W
Description & Applications	• DBS mixer applications to 12 GHz • Low noise figure • Low barrier type • Schottky barrier diode in series.
描述与应用	•DBS混频器应用到12 GHz •低噪声系数 •低门槛类型 •肖特基势垒二极管串联。
