| 类型 Type | 低通 Low Pass |
| 技术 Technology | LC |
| 通道数 Number of Channels | 1 |
| 中心/截止频率 Center / Cutoff Frequency | |
| 衰减值 Attenuation Value | |
| 电阻 - 通道 (Ω) Resistance - Channel (Ohms) | 100Ω |
| 电流 Current | 25mA |
| 数值 Values | C=47pF |
| ESD 保护 ESD Protection | 无 No |
| Description & Applications | Features 1. Murata's original inner design realizes small and low profile of 2.0x1.25x0.5mm. 2. Distributed constant circuit realizes smooth change of impedance which prevents reflection of signal and distortion of wave shape. 3. The NFR21G series is effective in a line where ground is not stable, because the resistance element in the filter absorbs noise and returns it to ground line. 4. The NFR21G series has no polarity so it can be used in dual direction transport lines. 5. The NFR21G series has various lineups of resistance (22 to 100 ohm) and capacitance (10 to 100pF). n Applications Interface lines and clock lines where signals are tend to be distorted |
| 描述与应用 | 特点 1。村田制作所的独特内部设计实现小 低调2.0x1.25x0.5mm。 2。分布常数电路实现平稳的变化 的阻抗，防止信号的反射 和波形失真。 3。 NFR21G系列是在一条线上的有效 地面的不稳定，因为电阻 在过滤器中的元素吸收噪声并将其返回 接地线。 4。 NFR21G系列没有极性，因此它可以 用于双向传输线。 5。 NFR21G系列有各种阻力 （22至100欧姆）和电容（10到100pF）。 施氮 接口线和时钟线的信号往往 被扭曲 |
