RC431ACM Voltage Reference Power Management IC 1.24V~12V SOT-153/SOT23-5 marking 431A Low VoltageAdjustable Precision shunt regulator
| 参考类型 Reference Type | |
| 输出电压Vo Voltage - Output | 1.24V~12V |
| 误差 Tolerance | ±1% |
| 温度系数 Temperature Coefficient | |
| 输入电压 Voltage - Input | 1.24V~12V |
| 阴极电流 Current - Cathode | 80µA |
| 输出电流IOUT Current - Output | 15mA |
| Description & Applications | FEATURES • Low-Voltage Adjustable Precision Shunt Regulator • Low voltage operation to 1.24V • 1% reference voltage tolerance • Output voltage adjustable from Vref to 12V • Low 80µA operational cathode current • 0.25Ω typical output impedance • TO-92, SOT23-3 and SOT23-5 packages Applications • Voltage reference for discrete power circuits |
| 描述与应用 | 特点 •低电压可调精密并联稳压器 •至1.24V的低电压操作 •1％的基准电压容差 •输出电压可调从Vref到12V的 •低操作阴极电流80μA •0.25Ω典型的输出阻抗 •TO-92，SOT23-3和SOT23-5封装 应用 •分立功率电路的参考电压 |
