TSMC39A TVS/ESD 33.3V 27.8A DO-214AB/SMC-39V marking TC

Hot selling goods

Product description
极性
Polarization
单向 Unidirectional
反向关断电压/工作电压VRWM
Reverse Standoff Voltage
33.3V
反向击穿电压VBR
Breakdown Voltage
39V
峰值脉冲耗散功率PPPM
Peak Pulse Power Dissipation
1500W
峰值脉冲电流IPPm
Peak Forward Surge Current
27.8A
额定耗散功率Pd
Power dissipation
Description & ApplicationsSpecification Features: •Vishay General Semiconductor •Surface Mount Automotive Transient Voltage Suppressors High Temperature Stability and High Reliability Conditions •Patented PAR® construction •Available in uni-directional polarity only •1500 W peak pulse power capability with a 10/1000 µs waveform •Excellent clamping capability •Very fast response time •Low incremental surge resistance •Meets MSL level 1, per J-STD-020, LF maximum peak of 260 °C •Solder dip 260 °C, 40 s •Component in accordance to RoHS 2002/95/EC and WEEE 2002/96/EC
描述与应用规格特点: •威世通用半导体 •表面贴装汽车瞬态电压抑制器的高温稳定性和高可靠性的条件 •专利的PAR®建设 •只可在单向极性 •1500瓦的峰值脉冲功率与10/1000μs波形能力 •出色的钳位能力 •非常快的响应时间 •低增量浪涌电阻 •会见MSL每1,J-STD-020,LF最大峰值为260°C •浸焊260°C,40秒 •组件按照RoHS 2002/95/EC和WEEE2002/96/EC
