UMD4 NPN+PNP Complex Bipolar Digital Transistor 50V/-50V 30mA/-70mA 150mW/120mW SOT-363/UMT6/SC-88/SC70-6 marking D4 switching inverting interface driver circuit
| 集电极-基极反向击穿电压V(BR)CBO Collector-Base Voltage(VCBO) | 50V/-50V |
| 集电极-发射极反向击穿电压V(BR)CEO Collector-Emitter Voltage(VCEO) | 50V/-50V |
| 集电极连续输出电流IC Collector Current(IC) | 30mA/-70mA |
| Q1基极输入电阻R1 Input Resistance(R1) | 47KΩ/Ohm |
| Q1基极-发射极输入电阻R2 Base-Emitter Resistance(R2) | 47KΩ/Ohm |
| Q1电阻比(R1/R2) Q1 Resistance Ratio | 1 |
| Q2基极输入电阻R1 Input Resistance(R1) | 10KΩ/Ohm |
| Q2基极-发射极输入电阻R2 Base-Emitter Resistance(R2) | 47KΩ/Ohm |
| Q2电阻比(R1/R2) Q2 Resistance Ratio | 0.213 |
| 直流电流增益hFE DC Current Gain(hFE) | |
| 截止频率fT Transtion Frequency(fT) | 250MHz |
| 耗散功率Pc Power Dissipation | 150mW/120mW |
| Description & Applications | Features • General purpose (dual digital transistors) • Both the DTA114Y chip and DTC144E chip in an EMT6 or UMT6 package. • Mounting possible with EMT3 or UMT3 automatic mounting machines.. • Transistor elements are independent, eliminating interference. • Mounting cost and area can be cut in half. |
| 描述与应用 | 特点 •通用（双数字晶体管） •两个DTA114Y的芯片和芯片的EMT6或UMT6的包DTC144E。 •安装EMT3或UMT3自动的安装机器可能.. •晶体管元素是独立的，消除干扰。 •安装成本和面积可减少一半。 |
