XP1214 NPN+NPN Complex Bipolar Digital Transistor 50V 0.1A R1=10KΩ R2=47KΩ 150mW/0.15W SOT-353/SC-88A/SC70-5 marking 9H switching inverting interface driver circuit

Hot selling goods

Product description

V(BR) CBO

Collector-Base Voltage

 50V

V(BR) CEO

Collector-Emitter Voltage

 50V
Collector Current(IC)  100MA
Input Resistance(R1)  10KΩ
Base-Emitter Resistance(R2)  47KΩ
Base-Emitter Input Resistance Ratio (R1/R2)  0.21
DC Current Gain(hFE)  80
Transtion Frequency(fT)  150MHZ
Power Dissipation (Pd)  150MW/0.15W
Description & Applications  Silicon NPN epitaxial planer transistor
For switching/digital circuits
UN1214 × 2
