ba032lbsg LDO Voltage Regulator 3.2V 90mV SOT-153/SMP5/SOT23-5 marking 32 Short-Circuit Protection Over-Temperature Protection
| 电路数量 Number of Regulators | 1 |
| 输入电压VIN Voltage - Input | 9 |
| 输出电压VOUT Voltage - Output | 3.2V |
| 输出电流Io Current - Output | 150mA/0.15A |
| 最大压降VDO Voltage - Dropout | 90mV |
| 带使能脚EN/CE(ON/OFF功能) With Enable Pin | 无 No |
| 最大耗散功率Pd Power dissipation | 170mW/0.17W |
| Description & Applications | Super-mini package regulator IC ；• Internal output transistor (IO=150mA) •Internal temperature protection circuit •Power-saving function enables designs with low current consumption • High level of ripple rejection (R.R.=66dB) •SMP5 super-mini package enables space-saving designs •Low I / O voltage differential (90mV Typ. at IO=50mA) |
| 描述与应用 | 超小型封装稳压集成电路;•内部的输出晶体管（IO=150MA） •内部温度保护电路 •省电功能使得设计与低电流消耗 •高级别纹波抑制（R.R.=66分贝的） •SMP5超小型封装可节省空间的设计 •低I/ O电压差（90mV的典型IO=50毫安） |
