ZRA125F02TA Voltage Reference Power Management IC 1.25V SOT-23 marking 12B Precision Micropower Voltage Reference
| 参考类型 Reference Type | 旁路，精度 Shunt, Precision |
| 输出电压Vo Voltage - Output | 1.25V |
| 误差 Tolerance | ±1% |
| 温度系数 Temperature Coefficient | 90ppm/°C |
| 输入电压 Voltage - Input | |
| 阴极电流 Current - Cathode | 50µA |
| 输出电流IOUT Current - Output | 5mA |
| Description & Applications | FEATURES • PRECISION 1.25 VOLT MICROPOWER VOLTAGE REFERENCE • No stabilizing capacitor required • Typical TC30ppm/°C • Typical slope resistance 0.65 • ± 3% and 2% tolerance • Industrial temperature range • Operating current 50 A to 5mA • Transient response, stable in less than 10 s • Small outline SOT23 package APPLICATIONS • Battery powered and portable equipment • Metering and measurement systems • Instrumentation • Data acquisition systems • Precision power supplies • Test equipment |
| 描述与应用 | 特点 •精密1.25伏微功耗电压基准 •无稳定电容 •典型TC30ppm/°C •典型的斜率电阻0.65 •±3％和2％容差 •工业温度范围 •工作电流50？到5mA •瞬态响应，性能稳定，在不到10s •小外形SOT23封装 应用 •电池供电和便携式设备 •计量和测量系统 •仪表 •数据采集系统 •精密电源 •测试设备 |
