Chip Resistor - Surface Mount SL1TEFR033 0.33Ω 1W-0.033 marking 33M
| 电阻值 Resistance | 0.33Ω |
| 误差 Tolerance | ±1% |
| 温度系数 Temperature Coefficient | ±180(ppm/°C) |
| 功耗 Power Dissipation | 1W |
| Description & Applications | SMD type of small size, ultra-low resistance (3mΩ～) and high accuracy (±0.5％) resistor for current detection. Encapsulated with flame retardant resin molding. (UL94 V-0) Excellent dimension accuracy, mountability and shockresistance due to molded products. Excellent terminal strength and solderability due to structure of a metal plate terminal electrode. Easy to absorb the thermal expansion and shrinkage because of a metal plate terminal structure. Suitable for flow, reflow and iron solderings. Products with lead free termination meet EU-RoHS requirements. EU-RoHS regulation is not intended for Pbglass contained in electrode, resistor element and glass. |
| 描述与应用 | 是小型、超低电阻值（3mΩ～）、高精度（±0.5％）、 SMD形状的电流检测用电阻器。 是难燃性树脂（UL94 V-0）模压密封型。 由于是模压成形，尺寸精度高，装载性、耐冲击性好。 由于是金属端子电极，端子强度、焊接性优异。 是金属板端子电极结构，吸收热膨胀收缩。 对应波峰焊、回流焊、烙铁焊接。 端子无铅品，对应欧盟RoHS。电极、电阻膜层、玻璃 中所含铅玻璃，不包含在欧盟RoHS指令中。 |
