RF Mixer UPC2758T-E3 SOT-163 marking C1Y
| RF类型 RF Type | 手机，CDMA Cellular, CDMA |
| 频率 Frequency | 830MHz~900MHz |
| 混频器数 Number of Mixers | 1 |
| 增益 Gain | 9.5dB |
| 噪声系数 Noise Figure | 5.5dB~6.5dB |
| 辅助属性 Secondary Attributes | 带放大器 With Amplifier |
| 电源电流 Current - Supply | 8.7mA~10.6mA |
| 电源电压 Voltage - Supply | 2.7V~5.5V |
| Description & Applications | Features • 800MHz BAND MIXER GaAs MMIC • Low voltage operation +2.8V • Low current consumption 8.7mA typ. • High input IP3 +8dBm typ. @fRF=850.0+850.1MHz, PRF=-25dBm fLO=740MHz, PLO=-10dBm • High conversion gain 9.5dB typ. @fRF=850MHz, PRF=-25dBm fLO=740MHz, PLO=-10dBm, fIF=110MHz • Low noise figure 5.5dB typ. @fRF=850MHz fLO=740MHz, PLO=-10dBm, fIF=110MHz • Ultra small & ultra thin package FLP6-B2 (Mount Size: 2.1x2.0x0.75mm) |
| 描述与应用 | 特点 •800MHz频段混频器的GaAs MMIC •低电压操作+2.8 V •低电流消耗8.7毫安典型。 •高输入IP3+8 dBm（典型值）。 @ FRF=850.0850.1兆赫，PRF=-25dBm FLO =740MHZ，PLO=-10dBm •高转换增益9.5分贝典型。 @ FRF =850MHz，PRF=-25dBm FLO =740MHZ，PLO=-10dBm时，FIF=110MHz的 •低噪声系数5.5分贝典型。 @ FRF =850MHz FLO =740MHZ，PLO=-10dBm时，FIF=110MHz的 •超小型超薄封装FLP6的B2（安装尺寸：2.1x2.0x0.75mm） |
