MM3143ENRE LDO Voltage Regulator 3.4V 220mV/0.22V SOT-153/SOT-25A/SOT23-5 marking A5L Short-Circuit Protection Over-Temperature Protection

Hot selling goods

Product description
电路数量
Number of Regulators
1
输入电压VIN
Voltage - Input
2~6V
输出电压VOUT
Voltage - Output
3.4V
输出电流Io
Current - Output
最大压降VDO
Voltage - Dropout
220mV/0.22V
带使能脚EN/CE(ON/OFF功能)
With Enable Pin
无 No
最大耗散功率Pd
Power dissipation
Description & Applications IC for 150mA Regulator ;I/O voltage difference 0.22V typ. (IO=150mA, VOUT=3.0V) •Output noise voltage 30µVrms typ. •Recommended maximum output current 150mA max. •No-load current consumption 45µA typ. • High ripple rejection rate 70dB (1kHz, IOUT=30mA) •Output voltage rank 1.2~5.0V (0.1V steps) •Output ON/OFF control function High: ON, Low: OFF
描述与应用150mA的稳压器IC;•I / O电压差0.22V典型值(IO=的150mA,VOUT= 3.0V) 输出噪声电压典型30μVRMS •推荐最大输出电流最大150mA。 •空载电流消耗45μA(典型值) •高纹波抑制率70分贝(1千赫,IOUT=30毫安) •输出电压等级1.2〜5.0V(0.1V) •输出开/关控制功能:开,低:关
