Integrated Circuit（IC） AND gate SN74AUP1G08YZPR 5-DSBGA/5-WCSP marking G3
| 逻辑类型 Logic Type | 与门 AND Gate |
| 电路数 Number of Circuits | 1 |
| 输入数 Number of Inputs | 2 |
| 电源电压Vcc Voltage - Supply | 0.8V~3.6V |
| 静态电流Iq Current - Quiescent (Max) | 10uA |
| 输出高，低电平电流 Current - Output High, Low | -4mA,4mA |
| 低逻辑电平 Logic Level - Low | 0.44V |
| 高逻辑电平 Logic Level - High | 2.6V |
| 传播延迟时间@Vcc，CL Max Propagation Delay @ V, Max CL | 2.4nS @ 3v 5pF |
| Description & Applications | LOW-POWER SINGLE 2-INPUT POSITIVE-AND GATE ；Available in the Texas Instruments NanoStar™ • Wide Operating VCC Range of 0.8 V to 3.6 V Package • Optimized for 3.3-V Operation • Low Static-Power Consumption: • 3.6-V I/O Tolerant to Support Mixed-Mode ICC = 0.9 μA Max Signal Operation • Low Dynamic-Power Consumption: • tpd = 4.3 ns Max at 3.3 V Cpd = 4.3 pF Typ at 3.3 V • Suitable for Point-to-Point Applications • Low Input Capacitance: Ci = 1.5 pF Typ • Latch-Up Performance Exceeds 100 mA Per • Low Noise: Overshoot and Undershoot JESD 78, Class II<10% of VCC • ESD Performance Tested Per JESD 22 • Ioff Supports Partial-Power-Down Mode – 2000-V Human-Body Model Operation (A114-B, Class II) • Schmitt-Trigger Action Allows Slow Input – 1000-V Charged-Device Model (C101) Transition and Better Switching Noise Immunity at the Input (Vhys = 250 mV Typ at 3.3 V) |
| 描述与应用 | 低功耗单路2输入正与门;可用的德州仪器NANOSTAR中™•宽工作VCC范围为0.8 V至3.6 V 包装•3.3-V操作优化 •低静态功耗： •3.6-V的I / O宽容，支持混合模式 ICC=0.9μA最大信号操作 •低动态功耗： •TPD =4.3 ns最大在3.3 V CPD =4.3 pF（典型值）在3.3 V •适用于点至点的应用 •低输入电容：CI= 1.5 pF（典型值） •闭锁性能超过100 mA每 •低噪声：过冲和下冲JESD 78，II类 |
