TC55RP4001ECB713 LDO Voltage Regulator 4V 400mV/0.4V SOT-23 marking 4A Short-Circuit Protection Over-Temperature Protection
| 电路数量 Number of Regulators | 1 |
| 输入电压VIN Voltage - Input | 12V |
| 输出电压VOUT Voltage - Output | 4V |
| 输出电流Io Current - Output | 200mA/0.2A |
| 最大压降VDO Voltage - Dropout | 400mV/0.4V |
| 带使能脚EN/CE(ON/OFF功能) With Enable Pin | 无 No |
| 最大耗散功率Pd Power dissipation | 240mW/0.24W |
| Description & Applications | 1µA LOW DROPOUT POSITIVE VOLTAGE REGULATOR •Very Low Dropout Voltage 120mV typ at 100mA 380mV typ at 200mA •High Output Current 250mA (VOUT = 5.0V) •High Accuracy Output Voltage ± 2% (± 1% Semicustom Version) •Wide Output Voltage Range 1.1V-6.0V •Low Power Consumption 1.1µA (Typ.) •Low Temperature Drift ± 100ppm/°C (Typ.) •Excellent Line Regulation 0.2%/V (Typ.) •Package Options 3-Pin SOT-23A •3-Pin SOT-89 •Short Circuit Protection •Custom Voltages Available from 1.1V to 6.0V in •0.1V Steps for a 2%, and 2.0V to 6.0V for a 1% Tolerance •Battery-Powered Devices •Cameras and Portable Video Equipment •Pagers and Cellular Phones •Solar-Powered Instruments •Consumer Products |
| 描述与应用 | 1uA的低漏失正电压稳压器 •非常低压差....在100mA时为120mV（典型值） 在200mA380mV（典型值） •高输出电流250mA（VOUT=5.0V） •高精度输出电压±2％ （±1％的半定制版） •宽输出电压范围1.1V-6.0V •低功耗1.1μA（典型值） •低温度漂移温度系数±100ppm/°C（典型值） •卓越的线路调整率0.2％/ V（典型值） •包装选项3引脚SOT-23A •3引脚SOT-89 •短路保护？ •自定义电压可从1.1V至6.0V •0.1V步骤为2％，1％容差的2.0V至6.0V •电池供电设备 •相机和便携式视频设备？ •寻呼机和手机 •太阳能供电的仪器 •消费类产品 |
