Integrated Circuit（IC） AND gate TC7WH08FC CST8 marking H34
| 逻辑类型 Logic Type | 与门 AND Gate |
| 电路数 Number of Circuits | 1 |
| 输入数 Number of Inputs | 2 |
| 电源电压Vcc Voltage - Supply | 2V~5.5V |
| 静态电流Iq Current - Quiescent (Max) | 2µA |
| 输出高，低电平电流 Current - Output High, Low | -25mA,25mA |
| 低逻辑电平 Logic Level - Low | 0.5V~1.65V |
| 高逻辑电平 Logic Level - High | 1.5v~3.85v |
| 传播延迟时间@Vcc，CL Max Propagation Delay @ V, Max CL | 4.3ns @ 5V，15pF |
| Description & Applications | Dual 2-Input AND Gate ;High speed operation : tpd = 4.3ns (typ.) at VCC = 5V, CL = 15pF • Low power dissipation : ICC = 2μA (max) at Ta = 25°C • High noise immunity : VNIH = VNIL = 28% VCC (min) • Operating voltage range : VCC = 2 to 5.5 V • 5.5-V tolerant inputs |
| 描述与应用 | 双2输入与门;高速：TPD=3.8ns电源VCC= 5 V（典型值） •低功耗：ICC=2μA（最大值）在Ta= 25°C •高噪声，免疫力：VNIH= VNIL=28％VCC（最小） •工作电压范围：VCC（opr.）=2〜5.5V •5.5-V宽容的投入。 |
