UP04401G08S0 Complex Bipolar Transistor PNP+PNP -60V -0.1A HEF=180~390 80MHZ MARKING 5K
|
V(BR) CBO Collector-Base Voltage |
-60V |
|
V(BR) CEO Collector-Emitter Voltage |
-50V |
| Collector Current(IC) | -100MA |
| Transtion Frequency(fT) | 80MHZ |
| DC Current Gain(hFE) | 180~390 |
|
VCE(sat) Collector-Emitter Saturation Voltage |
-0.5V |
| Power Dissipation (Pd) | 125MW/0.125W |
| Description & Applications | Silicon PNP epitaxial planar type
For general amplification
Features
Two elements incorporated into one package (Each transistor is separated)
Reduction of the mounting area and assembly cost by one half
Basic Part Number
2SB0709A × 2
|
| Technical Documentation Download | Read Online |
