UPA608T NPN+PNP Complex Bipolar Transistor 60V/-25V 100mA/-500mA 90~600/110~400 SOT-163/SC-74 marking OA switch and digital circuit application

Model：UPA608T
Mark / screen / code / typing：OA
Manufacturer：
Date Code：05+ 05+
Package：SOT-163/SC-74
Standard Package：3000
Min Order：10

Hot selling goods

Product description

集电极-基极反向击穿电压V(BR)CBO Collector-Base Voltage(VCBO)	60V/-25V
集电极-发射极反向击穿电压V(BR)CEO Collector-Emitter Voltage(VCEO)	50V/-16V
集电极连续输出电流IC Collector Current(IC)	100mA/-500mA
截止频率fT Transtion Frequency(fT)	250MHz/50MHz
直流电流增益hFE DC Current Gain(hFE)	90~600/110~400
管压降VCE（sat） Collector-Emitter Saturation Voltage	150mV/-250mV
耗散功率Pc Power Dissipation	300mW
Description & Applications
描述与应用
