XP4314 NPN+PNP Transistors with built-in resistor 50V 0.1A R1=10KΩ R2=47KΩ SOT-363/SC-88 marking 7X switch and digital circuit application

Hot selling goods

Product description





Q1  Collector-Base Voltage(VCBO)  50V
Q1Collector-Emitter Voltage(VCEO)  50V
Q1 Collector Current(IC) 100MA
Q2 Collector-Base Voltage(VCBO)  -50V
Q2Collector-Emitter Voltage(VCEO)  -50V
Q2Collector Current(IC)  -100MA/-0.1A
Q1 Input Resistance(R1)  10 KΩ
Q1Base-Emitter Resistance(R2)   47KΩ
Q1(R1/R2) Q1 Resistance Ratio  0.21
Q2 Input Resistance(R1)  10 KΩ
Q2Base-Emitter Resistance(R2)  47 KΩ
Q2(R1/R2) Q2 Resistance Ratio  0.21
 DC Current Gain(hFE) Q1/Q2  80 / 80
Transtion Frequency(fT) Q1/Q2  150MHZ /80MHZ
 Power Dissipation  150MW/0.15W
Description & Applications
Silicon NPN epitaxial planer transistor (Tr1)
Silicon PNP epitaxial planer transistor (Tr2)
Two elements incorporated into one package.
(Transistors with built-in resistor)
 UN2214+UN2114
