XP6114 PNP+PNP Complex Bipolar Digital Transistor -50V -100mA HEF=80 150mW/0.15W SOT-363/SC-88/SC70-6 marking CK switching inverting interface driver circuit
|
V(BR) CBO Collector-Base Voltage |
-50V |
|
V(BR) CEO Collector-Emitter Voltage |
-50V |
| Collector Current(IC) | -100MA/-0.1A |
| Input Resistance(R1) | 10KΩ |
| Base-Emitter Resistance(R2) | 47KΩ |
| Base-Emitter Input Resistance Ratio (R1/R2) | 0.21 |
| DC Current Gain(hFE) | 80 |
| Transtion Frequency(fT) | 80MHZ |
| Power Dissipation （Pd） | 150MW/0.15W |
| Description & Applications | Silicon PNP epitaxial planer transistor
For switching/digital circuits
■ Features
● Two elements incorporated into one package.
(Transistors with built-in resistor)
● Reduction of the mounting area and assembly cost by one half.
● UN1114 × 2 elements
|
